Thank you for choosing FLOWSOLV™. FLOWSOLV™ is a liquid and gas flow calculation software package to size meters and verify flow computer calculations, FLOWSOLV™ provides robust calculations, that are rigorously traceable to national and international standards. The calculations included in this version are listed below:-



Liquid Calculations

Gas Calculations

Meters

Composite Oil Calculation : API2540 MPMS Ch.11.1
Orifice - AGA3:1992
Orifice - ISO5167:1980
Orifice - ISO5167:1991
Orifice - ISO5167:1997
Orifice - ISO5167:2003
Venturi - ISO5167:1980
Venturi - ISO5167:1991
Venturi - ISO5167:1997
Venturi - ISO5167:2003

Instruments
Densitometer - Solartron 7835/45/46/47
Properties

Base Sediment and Water
1980 Density Observed to Base
1980 Density Base to Observed
Isokinetic Flow



Meters
Orifice - AGA3:1992
Orifice - ISO 5167:1980
Orifice - ISO 5167:1991
Orifice - ISO 5167:1997
Orifice - ISO 5167:2003
Venturi - ISO 5167:1980
Venturi - ISO 5167:1991
Venturi - ISO 5167:1997
Venturi - ISO 5167:2003

Instruments

Gas Densitometer - Solartron 7810/11/12
RD Analyser Appendix A – Solartron 3098/96

RD Analyser Calibration Check – Solartron 3098/96
Properties

Density, Compressibility – AGA8: 1985/94

Speed of Sound – AGA10: 2003

Density, Compressibility, Calorific Value ISO 6976: 1983/95

Density, Compressibility, Heating Value - GPA 2172/2145
Density, Volume, Mass, PTZ - ISO6976, GPA2172

Sampler Lag Time
Murdock Wet Gas Correction

Orifice/Venturi Uncertainty - ISO 5167:1991





FLOWSOLV™ is a major upgrade to our FLOW98™ calculation package , building on our experience over the last 6 years, in  supplying flow calculation and modelling software. We welcome suggestions that will improve the usability and the range of calculations available. Please let us know if there is a feature, or calculation, you would like to see included in future versions.

You can contact us at the address and telephone number given in the support section of this site.



This online help system shows you how to install and begin using FLOWSOLV™. The Controls section will provide everything you need to operate the software.
